Allen-Bradley 160-DN2 User Manual

Publication 0160-5.18 - June 2003
DeviceNet Parameter Descriptions 5-7
Drive Display Parameters
(Read Only) (Continued)
Parameter
Number
Parameter Name
Object Mapping
(Class-Instance-
Attribute)
Description Units
15 [Preset Status] 0xB3-1-15 Open (0) and closed (1) state of TB3 inputs SW1, SW2, and SW3. Binary Number
16 [Analog Input] 0xB3-1-16 The analog input as a percent of full scale. 0.1%
17 [Fault Buffer 0] 0xB3-1-17 Most recent fault. Numeric Value
18 [Fault Buffer 1] 0xB3-1-18 Second most recent fault. Numeric Value
19 [Fault Buffer 2] 0xB3-1-19 Third most recent fault. Numeric Value
This parameter applies only to the Analog Signal Follower model.
This parameter applies only to the Preset Speed model.
Bit 3 Bit 2 Bit 1 Bit 0
SW1
SW2
SW3
Unused
