Publication 1734-UM002C-EN-P - July 2003
Preface 5
Related Products and
Documentation
The following table lists related POINT I/O products and
documentation:
If you need more information on these products, contact your local
Rockwell Automation/Allen-Bradley distributor, integrator or sales
office for assistance. For more information on the documentation,
refer to the Allen-Bradley Publication Index, publication SD499.
Guidelines for Using
Your Adapter
Remember the following operational guidelines when using your
1734-ADN(X) adapter.
Subnet 1734-ADNX only.
The Subnet DeviceNet Network, and is defined as the
DeviceNet link that provides the expansion of the POINTBus to
allow the 1734-ADNX to use its lower connector to add an
additional 500 meters and up to 63 nodes which will be
bridged through the 1734-ADNX up to the Primary Network.
Note that backplane modules are also part of the Subnet.
Term: Definition:
Document Cat. No. Publication
POINT I/O Technical Data 1734-Series 1734-TD002
POINT I/O Digital and Analog I/O Modules and POINTBlock I/O Modules User Manual 1734-Series and
1734D-Series
1734-UM001
POINT I/O Module Installation Instructions 1734-Series 1734-INxxx (Multiple numbers)
DeviceNet Communication Interface Installation Instructions 1734-PDN 1734-IN057
POINT I/O 24V dc Expansion Power Supply Installation Instructions 1734-EP24DC 1734-IN058
Field Potential Distributor Installation Instructions 1734-FPD 1734-IN059
General Installation Instructions All 1734 1734-IN510
Wiring Base Assembly Installation Instructions 1734-TB, -TBS 1734-IN511
Wiring Base Assembly Installation Instructions 1734-TB3, -TB3S 1734-IN013
Terminal Marking Kit 1492-PLTKIT 1492-UM001 and 1492-5.0
DeviceNet Cable System Planning and Installation Manual DN-6.7.2 DN-6.7.2
Industrial Automation Wiring and Grounding Guidelines N/A 1770-4.1
