3-10 Initial Setup and Mode Menu
To Simulate an Application:
1. Download the application from the DPS software.
2. From the Mode Menu, select item [4] Other.
The Other Menu appears:
3. Select item [3] Sim.
The simulate enable screen displays:
4. Press [1] to enable the Simulate mode.
The screen will display:
After the new parameter is saved, the MicroView will again
display:
5. Press [5] Ex to exit the Other Menu and display the Mode Menu.
6. From the Mode Menu, reset the MicroView.
The MicroView displays a series of diagnostic tests, enters run
mode, loads the application and then displays the Mode Menu
of the application.
1 Reset
2 Comm
3 Spec
4 Other
1 Code
2 Scale
3 Sim
4 Test
5 Ex
Current Setting
Simulate
0 = Off
OFF (0)
1 = On
COPYING TO MEM
Please Wait . . .
1 Code
2 Scale
3 Sim
4 Test
5 Ex
1 Reset
2 Comm
3 Spec
4 Other
