14 Rockwell Automation Publication IASIMP-QS035B-EN-P - April 2015
Chapter 1 Prepare the Kinetix 5500 Drive Hardware
Follow These Steps
Prepare the Panel
Ground the
Kinetix 5500
Drive
page 15
Mount the
Kinetix 5500
Drive
Connect the Kinetix 5500
Drive to the EtherNet/IP
Network
page 16
page 19
Wire Drive
Connectors
page 20
L3
L2
L1
Remove
For DC
Bus Only
Apply the Single Motor
Cable Shield Clamp
page 28
page 30
Assign an IP Address to
the Kinetix 5500 Drive
page 31
PRECHARAGE
192.168.1.1
DC BUS: 0.3V
SETUP
MENU
SETUP
MENU
PRECHARGE
192.168.1.1
DC BUS: 0.3V
