Chapter 1 Add a Kinetix 5500 Drive to a Logix Designer Application
Follow These Steps
Add the Kinetix 5500
Drive to the Logix
Designer Project
page 35
Configure the
Motion Group
page 39
Configure Axis
Properties
page 40
Apply Power to the
Kinetix 5500 Drive
page 42
Test and Tune the Axis
page 43
