Rockwell Automation Publication IASIMP-QS035B-EN-P - April 2015 7
Preface
About This Publication
This quick start provides examples and procedures for integrating a Kinetix® 5500 drive into any Logix5000™ control
system over an EtherNet/IP network. The programming examples are not complex, and offer easy solutions to verify that
t
he devices function and communicate properly.
This quick start describes how to use one device on one network in a Logix5000 control system. Typically, a Logix5000
con
trol system, operating on an EtherNet/IP network, includes a controller, power supply, and communication modules.
But, in addition, the system can also include remote I/O modules, servo and/or AC drives, and HMI terminals.
Other quick starts describe how to use different devices on various networks in Logix5000 control systems. For more
i
nformation, see Integrated Architecture™: Logix5000 Control Systems Quick Starts Quick Reference, publication
IASIMP-QR024.
The beginning of each chapter contains the following information. Read these sections carefully before you start work in
each ch
apter:
• Be
fore You Begin - This section lists the steps that must be completed and decisions that must be made before
starting that chapter. You do not have to complete the chapters in this quick start in the order in which they appear,
but this section defines the minimum amount of preparation required before completing the current chapter.
• W
hat You Need - This section lists the tools that are required to complete the steps in the current chapter. The the
tools that are required include, but are not limited to, hardware and software.
• Fo
llow These Steps - This section illustrates the steps in the current chapter and identifies which steps are required
to complete the examples using specific networks.
This publication describes example procedures that you can complete when using a Kinetix 5500 drive over an EtherNet/IP
network. The tasks that are described are not the only tasks you can complete when using a Kinetix 5500 drive in a typical
Logix5000 control system.
