Allen-Bradley PowerFlex 6000 User Manual

Rockwell Automation Publication 6000-UM002E-EN-P - April 2018 131
Appendix A
Technical Specifications
Table 10 - Specifications
Description
Power Rating Range @ 2.3/2.4 kV motor voltage 137...2390 kW (183...3205 HP)
Power Rating Range @ 3.0 kV motor voltage 160...2990 kW (214...4010 HP)
Power Rating Range @ 3.3 kV motor voltage 176...3280 kW (235...4398 HP)
Power Rating Range @ 4.0/4.16 kV motor voltage 220...4140 kW (294...5552 HP)
Power Rating Range @ 6.0 kV motor voltage 200...5970 kW (268...8006 HP)
Power Rating Range @ 6.6 kV motor voltage 286...6570 kW (384...8810 HP)
Power Rating Range @ 6.9 kV motor voltage 286...6870 kW (384...9213 HP)
Power Rating Range @ 10.0 kV motor voltage 200...9950 kW (268...13343 HP)
Power Rating Range @ 11.0 kV motor voltage 200...10950 kW (268...14684 HP)
Motor Type Induction (asynchronous) motors
Input Voltage Rating 2.4 kV,
3.0 kV, 3.3 kV,
4.16 kV,
6.0 kV, 6.3 kV, 6.6 kV,
6.9 kV,
7.2 kV,
10.0 kV,
11.0 kV
For other input voltage ratings, contact your local sales representative or factory.
Input Voltage Tolerance ±10% of Nominal
Input Voltage Sag, minimum -30% of Nominal
Input Frequency 50/60 Hz, ±5%
Input Impedance Device Multiphase Isolation Transformer
Input Current THD (1st...49th) Complies with IEEE519-1992 standard
Output Voltage 0...2300/2400V,
0...3000/3300V,
0...4000/4160V,
0...6000/6300V/6600V,
0...6900V,
0...10000V
0...11000V
Rectifier Configurations 18 pulse (2.3/2.4/3.0/3.3 kV),
24 pulse (4.0/4.16 kV),
30 pulse (6.0 kV),
48 pulse (10 kV),
54 pulse (11 kV)
Inverter Configuration Pulse Width Modulated (PWM) power modules
Power Module Rating 40 A, 75 A, 100 A, 120 A, 150 A, 180 A, 200 A, 250 A, 305 A, 350 A, 438 A, 560 A, 680 A
Power Semiconductors Diodes (rectifier), IGBTs (inverter)
Medium Voltage Isolation Fiber Optic
Control Method Sensorless Vector Control and Volts per Hertz
Output Frequency Range 0.5…75 Hz
Acceleration/Deceleration time 0...3276 seconds configurable
Ride Through, minimum 5 cycles
Flying Start Capability Yes
Service Duty Rating Normal duty – 120% overload for 1 min every 10 min
Heavy duty – 150% overload for 1 min every 10 min
Input Power Factor >.95
VFD Efficiency
(1)
>96.5%
VFD Noise Level < 85 dB, depends on drive rating
Operator Interface 7 in. WinCE Color Touchscreen
Languages English, Chinese, Spanish, Portuguese, Russian, German, French, Italian, Polish, Korean, Japanese, Turkish, Czech
