Chapter 3 Setup and Operation
Open/Close Bypass Contactors
1. Under Contactor Operation, press either or
.
2. Select to confirm in the Close Bypass Contactors? or Open
Bypass Contactors? dialog box.
IMPORTANT
Turn the 3-position on the selector switch on the front of the LV cabinet to the
Bypass position.
ATTENTION: Operations
in this graphic can only
operate while on local
control.
ATTENTION: This operation
can only operate while drive
is not running.
