Allen-Bradley PowerFlex 6000 User Manual

Rockwell Automation Publication 6000-UM002E-EN-P - April 2018 66
Parameters and Function Codes Chapter 4
P Parameters
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
P007Number of Power Cells Per Phase0 9333344566689 OfflineYY P008 Motor Rotation Direction Under
Local Control 0 = Reverse 1 = Forward
0 1111111111111 OfflineYY
P009 Motor Rotation Direction Command
Selection 0 = Local 1 = DCS
0 1000000000000 OfflineYY
P011 Power Cell DC Bus Rated Voltage 50 1300 650 650 920 920 848 848 976 920 920 976 976 976 V Offline Y Y P012 Motor Rated Voltage 0 32767 2300 2400 3000 3300 4000 4160 6000 6300 6600 6900 10000 11000 V Offline Y Y P013Motor Rated Power 0 32767000000000000kWOfflineYY P014 Motor Rated Speed 0 5000 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 RPM Offline Y Y P015 Motor Rated Power Factor 0 100 87.99 87.99 87.99 87.99 87.99 87.99 87.99 87.99 87.99 87.99 87.99 87.99 % Offline Y Y P017Number of Motor Pole Pairs 0 100222222222222 Offline Y P019 Encoder Resolution 0 4096 1024 1024 1024 1024 1024 1024 1024 1024 1024 1024 1024 1024 Offline Y
P024 Stop Method
0 = Ramp Down 1 = Coast Stop
0 1000000000000 On/OffYY
P025 Flux Reduction Enable
0 = Disable 1 = Enable
0 1000000000000 On/Off Y
P030 Powercell Fault Trip Signal Mask -32768 32767 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 Offline Y Y P031 System Fault Trip Signal Mask -32768 32767 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 Offline Y Y P034 Current Stability Loop Filter Time 0 32767 63 63 63 63 63 63 63 63 63 63 63 63 On/Off Y P035 Current Stability Loop Frequency
Range1 Output Scaling Factor
0 100 15 15 15 15 15 15 15 15 15 15 15 15 On/Off Y Y
P036 Current Stability Loop Output Upper
Limit
0 100 10 10 10 10 10 10 10 10 10 10 10 10 On/Off Y
P037 Current Stability Loop Output Lower
Limit
-100 100 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 On/Off Y
P038 Current Stability Loop Enable
0 = Disable 1 = Enable
0 1000000000000 On/Off Y
