Chapter 4 Parameters and Function Codes
P039 Current Stability Loop Enable
Frequency Range1 Upper limit
0 100 30 30 30 30 30 30 30 30 30 30 30 30 On/Off Y
P040 Safe Start Condition
0 = Zero Frequency Command
Required
1 = Frequency Command Allowed
0 1111111111111 OfflineYY
P041 Power Cell Bypass Enable
0 = Disable
1 = Enable
0 1000000000000 OfflineYY
P042 Power Cell Bypass Delay After Power
Cell Bypassed
20 16000 500 500 500 500 500 500 500 500 500 500 500 500 ms On/Off Y
P043 Power Cell Bypass Upper Limit For
Bypassed Feedback Time
30 500 100 100 100 100 100 100 100 100 100 100 100 100 ms On/Off Y
P044 Power Cell Bypass Fault Simulation
Power Cell Count
0 3000000000000 On/OffYY
P045 Load Loss Control Enable
0 = Disable
1 = Enable
0 1000000000000 On/OffYY
P046Load Loss Enable Frequency 0 100202020202020202020202020%On/OffYY
P047 Load Loss Control Differential
Scaling
0 2000888888888888%On/Off Y
P048 Load Loss Frequency Compensation
Upper Limit
0 5555555555555%On/OffYY
P049Load Loss Control Scaling Factor0 2000000000000000%On/Off Y
P050Load Loss Control Integral Time0 100000000000000msOn/Off Y
P051 Load Loss Control Filter Time 0 200 100 100 100 100 100 100 100 100 100 100 100 100 ms On/Off Y
P052Load Loss Enable Current Threshold0 100101010101010101010101010%On/Off Y
P053 Load Loss Control Exit Delay 0 16000 5000 5000 5000 5000 5000 5000 5000 5000 5000 5000 5000 5000 ms On/Off Y
P057 Power Cell Bypass Upper Limit Time
For Over Temperature
0 32767 10 10 10 10 10 10 10 10 10 10 10 10 s On/Off Y
P058 Power Cell Bypass Phase A Cell
Number For Simulation
0 9000000000000 On/OffYY
P059 Power Cell Bypass Phase B Cell
Number For Simulation
0 18000000000000 On/OffYY
P060 Power Cell Bypass Phase C Cell
Number For Simulation
0 27000000000000 On/OffYY
