Torque Requirements
Proper tightening torque must be used for installation and wiring.
Table 13 - Torque Requirements
Thread Size
Torque
Class 8.8
N•m lb•ft
M4 3.0 2.2
M5 5.9 4.4
M6 10.5 7.7
M8 26.0 19.2
M10 51.0 37.6
M12 89.0 65.7
M14 141.0 104.1
M16 215.0 158.7
M20 420.0 310.0
