Chapter 4 Parameters and Function Codes
P453 V/F Curve
0 = Linear
1 = Parabolic Curve
2 = Predefined Curve #1
3 = Predefined Curve #2
4 = 5 Point VF
5 = SVC
0 5555555555555 OfflineYY
P454Flux Time 0 102222222222 2sOffline Y
P455 Modulation Index 0.0 110.0 84.0 87.6 77.3 85.0 83.8 87.0 87.0 81.0 85.0 83.7 91.0 89.0 On/Off Y Y
P456 Motor Voltage Upper Limit 0.00 110.0 84.0 87.6 77.3 85.0 83.8 87.0 87.0 81.0 85.0 83.7 91.0 89.0 On/Off Y Y
P457 Flying Start Voltage Recovery Time
(Low Speed Region)
0.00 163.84 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 s On/Off Y Y
P458Coefficient A 0 100404040404040404040404040 Offline Y
P459 Flying Start Voltage Recovery Time
(High Speed Region)
0.00 163.84 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00 s On/Off Y Y
P460 Rated Output Frequency 0 75 50 50 50 50 50 50 50 50 50 50 50 50 Offline Y Y
P461 Restart Enable
0 = Disable
1 = Enable
0 1000000000000 On/OffYY
P462 Fault Reset Timeout 0.04 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 120.00 s On/Off Y
P463 Flying Start Low/High Speed
Regions Boundary
0 100 16 16 16 16 16 16 16 16 16 16 16 16 % On/Off Y Y
P465Power Cell Fault Auto Reset Delay0 10444444444444sOn/Off Y
P466 Maximum Output Frequency 0 75 50 50 50 50 50 50 50 50 50 50 50 50 Offline Y Y
P467 Over Speed Enable
0 = Disable
1 = Enable
0 1000000000000 OfflineYY
P470 Version Compatibility Enable
0 = Disable
1 = Enable
0 1111111111111 Offline Y
P471 Fault-To-Bypass
0 = Disable
1 = Enable
0 1000000000000 OfflineYY
P472Fault-To-Bypass Delay 0 5333333333333 On/OffYY
P473 Fault-To-Bypass Delay When
Starting The Motor
0 60606060606060606060606060s On/OffYY
No. Name Min. Max. Default Values Units Modify
Root
Access
2300V 2400V 3000V 3300V 4000V 4160V 6000V 6300V 6600V 6900V 10000V 11000V U S R
To Next Page
