Rockwell Automation Publication 1734-UM020B-EN-E - August 2019 33
Configure the POINT I/O 4 Channel IO-Link Master as IO-Link Master Using the Studio 5000 Add-on Profile Chapter 4
Register an IODD file
An IO-Link Device Description (IODD) file is a set of multiple files including a
file in XML format, which describes all parameters associated with the device.
The IODD set also includes graphic image files of the device and vendor logo.
Before you proceed with this task, take note that:
• Only IODD files based on IO-Link specification v1.0.1 or v1.1 can be
registered.
• You need administrator rights for the machine where the Add-on Profile is
installed to be able to register an IODD file.
To register an IODD file:
1. From the IO-Link tab, in the Channel tree, right-click on the IO-Link
channel.
2. Select Register IODD.
The following dialog box appears.
