Add the POINT I/O 4 Channel IO-Link Master
Module on an EtherNet/IP Network
Introduction
See the table for a list of where to find specific information in this chapter.
Install the POINT I/O 4
Channel IO-Link Master
Add-On Profile
Before you can use your POINT I/O 4 Channel IO-Link Master Module in
Studio 5000, you must set up the module profile so that it can be recognized.
Follow these steps to set up the profile.
Topic Page
Install the POINT I/O 4 Channel IO-Link Master Add-On Profile 19
Add a POINT I/O 4 Channel IO-Link Master Module to Studio 5000 23
IO-Link Tag Elements 27
I/O Tags 28
Configuration Data 28
The illustrations of the Studio 5000 Module Profile Setup
software dialog boxes shown in this manual are samples.
Because your system configurations or the firmware kits are
different, the dialog boxes you see when running the tool may
differ from the ones you see here.
To Next Page
