Preface
Related Publications
See this table for a list of related POINT I/O products and documentation. The
publications are available from https://literature.rockwellautomation.com/
. For
specification and safety certification information, see the installation
instructions.
Resource Description
POINT I/O 4 Channel IO-Link Master
POINT I/O 4 Channel IO-Link Master Installation Instructions,
publication 1734-IN043
Provides installation information and wiring diagrams for the
1734-4IOL module.
POINT I/O 4 Channel IO-Link Master Release Notes,
publication 1734-RN024
Release notes for the 1734-4IOL module
Communication Devices
POINT I/O EtherNet/IP Adapter Installation Instructions,
publication 1734-IN042
Provides installation information about 1734-AENT, Series B adapters.
POINT I/O Dual Port EtherNet/IP Adapter, publication 1734-IN041 Provides installation information about 1734-AENTR, Series B adapters.
POINT I/O EtherNet/IP Adapter Module User Manual,
publication 1734-UM018
Describes how to use 1734-AENT, Series B adapters.
POINT I/O and ArmorPOINT I/O Dual Port EtherNet/IP Adapters User
Manual, publication 1734-UM017
Describes how to use 1734-AENTR, Series B adapters.
Power Supplies, Wiring Base Assemblies, Miscellaneous
Field Potential Distributor Installation Instructions, publication 1734-IN059
Provides installation information about 1734-FPD distributors.
POINT I/O 24V DC Expansion Power Supply Installation Instructions,
publication 1734-IN058
Provides installation information about 1734-EP24DC power supplies.
POINT I/O 120/240V AC Expansion Power Supply Installation Instructions,
publication 1734-IN017
Provides installation information about 1734-EPAC power supplies.
POINT I/O Common Terminal Module Installation Instructions,
publication 1734-IN024
Provides installation information about 1734-CTM modules.
POINT I/O Voltage Terminal Module Installation Instructions,
publication 1734-IN024
Provides installation information about 1734-VTM modules.
POINT I/O Wiring Base Assembly Installation Instructions,
publication 1734-IN511
Provides installation information about 1734-TB and 1734-TBS assemblies.
POINT I/O Wiring Base Assembly Installation Instructions,
publication 1734-IN013
Provides installation information about 1734-TB3 and 1734-TB3S
assemblies.
POINT I/O One-piece Wiring Base Assembly Installation Instructions,
publication 1734-IN028
Provides installation information about 1734-TOP, 1734-TOPS, 1734-TOP3,
and 1734-TOP3S assemblies.
Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
Detailed information on proper wiring and grounding techniques.
