87 Publication 1734-UM011D-EN-P - May 2011
Appendix
B
Configure the RSLinx Ethernet
Communication Driver
What This Appendix
Contains
To communicate with your 1734-AENT adapter over your network you must
configure the RSLinx EtherNet/IP driver (AB_ETH/IP). You need one of
these drivers to download the example application programs in this manual.
See the table for a list of the contents of this appendix and where to find
specific information:
Install the RSLinx Software
Use this procedure to install RSLinx software on your computer.
1. Insert the CD in the CD-ROM drive.
Note that the CD-ROM supports Windows Autorun. Once inserted
into the CD-ROM drive, if you have Autorun configured, the
installation automatically starts at the first setup screen.
If Autorun is not configured for your CD-ROM drive, go to
step 2.
2. From the Start menu, choose Run.
The Run dialog appears.
3. Type d:/setup (if it doesn’t appear automatically), where d: is your
CD-ROM driver letter.
4. Click OK.
You see the progress bar, followed by the welcome screen.
Topic Page
Install the RSLinx Software 87
Configure the AB_ETH/IP Driver 88
You must use series C POINT I/O modules with the 1734-AENT
adapter. Series A or B POINT I/O modules will not work with
this adapter.
