Page #107 background image
Publication 1734-UM011D-EN-P - May 2011
POINT I/O Module and RSLogix 5000 Software Controller Tag Reference 93
Digital 2 POINT Input
1734-IA2
2 POINT 120V AC Input
1734-IB2
2 POINT 10…28V DC Input, Sink
1734-IM2
2 POINT 240V AC Input
1734-IV2
2 POINT 10…28V DC Input, Source
Configuration Data Data Type Default
Value
Valid Data Values
Filter Off On Time - POINT 0 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
(1)
POINT I/O Modules support the Unsigned Integer data type UINT (0…65,535 range).
RSLogix 5000 software supports the signed Integer data type INT (-32,768 …+32,767 range).
To enter Filter values from +32,768…+65,535 µs, use this conversion formula:
Desired Filter Value (in µs) - 65536 = Entered Filter Value (in µs).
As an example, for a 40 ms filter time, 40000 - 65536 = -25536
Filter On Off Time - POINT 0 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter Off On Time - POINT 1 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter On Off Time - POINT 1 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Input Data Data Type Default
Value
Valid Data Values
Input Data - POINT 0, 1 SINT, BIT 0 0=Off
1=On
Output Data Data Type Default
Value
Valid Data Values
None
