Allen-Bradley Rockwell Automation 1734-AENT - Digital 4 POINT Input

Publication 1734-UM011D-EN-P - May 2011
94 POINT I/O Module and RSLogix 5000 Software Controller Tag Reference
Digital 4 POINT Input
1734-IB4
4 POINT 10…28V DC Input, Sink
1734-IV4
4 POINT 10…28V DC Input, Source
Configuration Data Data Type Default
Value
Valid Data Values
Filter Off On Time - POINT 0 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
(1)
POINT I/O Modules support the Unsigned Integer data type UINT (0…65,535 range).
RSLogix 5000 software supports the signed Integer data type INT (-32,768…+32,767 range).
To enter Filter values from +32,768…+65,535 µs, use this conversion formula:
Desired Filter Value (in µs) - 65536 = Entered Filter Value (in µs).
As an example, for a 40 ms filter time, 40000 - 65536 = -25536
Filter On Off Time - POINT 0 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter Off On Time - POINT 1 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter On Off Time - POINT 1 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter Off On Time - POINT 2 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter On Off Time - POINT 2 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter Off On Time - POINT 3 INT 1,000
-32,768…32,767 µs
(1)
(0…65,535)
Filter On Off Time - POINT 3 INT 1,000
-32,768…32,767 µs
(1)
(0… 65,535)
Input Data Data Type Default
Value
Valid Data Values
Input Data - POINT 0, 1, 2, 3 SINT, BIT 0 0=Off
1=On
Output Data Data Type Default
Value
Valid Data Values
None
