Allen-Bradley Rockwell Automation 1734-AENT User Manual

Publication 1734-UM011D-EN-P - May 2011
POINT I/O Module and RSLogix 5000 Software Controller Tag Reference 95
Digital 2 POINT Output –
Without Diagnostic Status
1734-OA2
2 POINT 120V AC Output
1734-OW2
2 POINT AC/DC Relay Output
1734-OX2
2 POINT Relay Output N.O./N.C.
Configuration Data Data Type Default
Value
Valid Data Values
Fault Mode - POINT 0, 1 SINT, BIT 0 0=Fault Value
1=Hold Last State
Fault Value - POINT 0, 1 SINT, BIT 0 0=Off
1=On
Program Mode - POINT 0, 1 SINT, BIT 0 0=Program Value
1=Hold Last State
Program Value - POINT 0, 1 SINT, BIT 0 0=Off
1=On
Input Data Data Type Default
Value
Valid Data Values
None
Output Data Data Type Default
Value
Valid Data Values
Output Data - POINT 0, 1 SINT, BIT 0 0=Off
1=On

Allen-Bradley Rockwell Automation 1734-AENT Specifications

General

Model	1734-AENT
Category	Network Hardware
Type	EtherNet/IP Adapter
Ethernet Ports	2
IP Addressing	Static or DHCP
Network Address	Configurable via software
Mounting	DIN rail
Number of Ports	2
Port Type	RJ45
Communication Protocol	EtherNet/IP
Manufacturer	Rockwell Automation
Power Supply	24V DC
Enclosure	Open-style
