96 POINT I/O Module and RSLogix 5000 Software Controller Tag Reference
Digital 2 POINT Output –
With Over Load and Open
Load Diagnostic Status
1734-OB2E
2 POINT 10…28V DC Electronically Fused Output, Source
1734-OB2EP
2 POINT 10…28V DC Electronically Fused Protected Output, Source
Configuration Data Data Type Default
Value
Valid Data Values
Fault Mode - POINT 0, 1 SINT, BIT 0 0=Fault Value
1=Hold Last State
Fault Value - POINT 0, 1 SINT, BIT 0 0=Off
1=On
Program Mode - POINT 0, 1 SINT, BIT 0 0=Program Value
1=Hold Last State
Program Value - POINT 0, 1 SINT, BIT 0 0=Off
1=On
No Load Enable - POINT 0, 1
(Wire Off Diagnostic)
SINT, BIT 1 0=Disabled
1=Enabled
Auto Restart Enable - POINT 0, 1
(Over Load Behavior)
SINT, BIT 0 0=Latch Off
1=Auto Retry
Fault Latch Enable - POINT 0, 1
(Open Load or Over Load)
SINT, BIT 0 0=No Latching
1=Alarms Latch
Input Data Data Type Default
Value
Valid Data Values
Status Data - POINT 0, 1
(Open Load or Over Load)
SINT, BIT 0 0=Off
1=On (Load Fault)
Output Data Data Type Default
Value
Valid Data Values
Output Data - POINT 0, 1 SINT, BIT 0 0=Off
1=On

Allen-Bradley Rockwell Automation 1734-AENT Specifications

General

Model	1734-AENT
Category	Network Hardware
Type	EtherNet/IP Adapter
Ethernet Ports	2
IP Addressing	Static or DHCP
Network Address	Configurable via software
Mounting	DIN rail
Number of Ports	2
Port Type	RJ45
Communication Protocol	EtherNet/IP
Manufacturer	Rockwell Automation
Power Supply	24V DC
Enclosure	Open-style
