Publication 1734-UM011D-EN-P - May 2011
120 POINT I/O Module and RSLogix 5000 Software Controller Tag Reference
To enter values from +128…+255, use these conversion formulas:
Decimal Position
Desired Decimal Position Value - 256 = Entered Decimal Position
Value.
As an example, for a divisor of 200, 200 - 256 = -56
Gate Interval
Desired Gate Interval Value - 256 = Entered Gate Interval Value.
As an example, for a Gate Interval of 200, 200 - 256 = -56
Scalar
Desired Scalar Value - 256 = Entered Scalar Value.
As an example, for a Scalar of 128, 128 - 256 = -128
1734-IJ
1 Channel 5V DC Encoder / Counter
1734-IK
1 Channel 15…24V DC Encoder / Counter
Configuration Data Data Type Default
Value
Valid Data Values
SS Counter Control
SS Counter Reset
SS Counter Preset
SS Value Reset
SINT
BIT 0
BIT 1
BIT 2
0
0=Count Unchanged
1=Count Cleared
0=Count Unchanged
1=Count Set to Preset
0=Count Unchanged
1=Count Cleared
