Configura-
tion Value
Life Test
Jumper
Present
Comm
Board "B"
Header
Present
Comm
Board "A"
Header
Present
Vend Con-
nection
Present
Coin Drop
#2 Present
Coin Drop
#1 Present
62 YES YES YES YES YES NO
63 YES YES YES YES YES YES
Table 29
Configuration 2 Display Test d 30
This option is not used on this model.
Configuration 3 Display Test d 31
This option is not used on this model.
Configuration 4 Display Test d 32
This option shows the user which dipswitches are set on the con-
trol.
To start test, control must be in the Testing Mode. Refer to How
to Enter Testing Feature at the beginning of this section.
To Enter, press the START (enter) keypad. The display will show
d XXX with XXX representing a configuration value as shown in
Table 30 .
If supply voltage is 100-127 Volt per phase, the voltage configu-
ration should be 120 Volt.
If supply voltage is 200-240 Volt per phase, the voltage configu-
ration should be 240 Volt.
To exit Machine Configuration 4 Display Test, press the DELI-
CATES 30 (<) keypad. The control will return to the Testing
Mode.
Each column in the table below contains a unique combination of
the words “ON” and “OFF” that indicates if that column’s dips-
witch is set on or off when the value is displayed.
Configuration
Value
Dipswitch 8
Pump (OFF)
Gravity Drain
(ON)
Dipswitch 7
Heater Disa-
bled (OFF)
Heater Ena-
bled (ON)
Dipswitch 3
Payment Sys-
tem Not
Present (OFF)
Payment Sys-
tem Present
(ON)
Dipswitch 2
Energy Cycle
Dipswitch 1
120 Volt Sup-
ply (OFF)
240 Volt Sup-
ply (ON)
0 OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF ON
2 OFF OFF OFF ON OFF
3 OFF OFF OFF ON ON
4 OFF OFF ON OFF OFF
5 OFF OFF ON OFF ON
6 OFF OFF ON ON OFF
7 OFF OFF ON ON ON
64 OFF ON OFF OFF OFF
65 OFF ON OFF OFF ON
66 OFF ON OFF ON OFF
Table 30 continues...
Testing Machine and Electronic Control Functions
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
105 Part No. 805405ENR5
