ALLIANCE BF3JGBJG403UN01 - Configuration 5 Display Test D 33

Configuration
Value
Dipswitch 8
Pump (OFF)
Gravity Drain
(ON)
Dipswitch 7
Heater Disa-
bled (OFF)
Heater Ena-
bled (ON)
Dipswitch 3
Payment Sys-
tem Not
Present (OFF)
Payment Sys-
tem Present
(ON)
Dipswitch 2
Energy Cycle
Dipswitch 1
120 Volt Sup-
ply (OFF)
240 Volt Sup-
ply (ON)
67 OFF ON OFF ON ON
68 OFF ON ON OFF OFF
69 OFF ON ON OFF ON
70 OFF ON ON ON OFF
71 OFF ON ON ON ON
128 ON OFF OFF OFF OFF
129 ON OFF OFF OFF ON
130 ON OFF OFF ON OFF
131 ON OFF OFF ON ON
132 ON OFF ON OFF OFF
133 ON OFF ON OFF ON
134 ON OFF ON ON OFF
135 ON OFF ON ON ON
192 ON ON OFF OFF OFF
193 ON ON OFF OFF ON
194 ON ON OFF ON OFF
195 ON ON OFF ON ON
196 ON ON ON OFF OFF
197 ON ON ON OFF ON
198 ON ON ON ON OFF
199 ON ON ON ON ON
Table 30
Configuration 5 Display Test d 33
This option is not used on this model.
Factory Test
To Enter Factory Test
1. Be certain control is in Ready Mode or Start Mode and access
panel or coin vault is open.
2. While pressing and holding the C modifier keypad with one
hand, press the PERM PRESS 60 keypad with the other hand.
3. When the control enters Factory Test, it will display the first
test step, Machine Type.
4. The control will advance through the sequence of test steps
whenever START (enter) is pressed, with the exception of the
Keypad Test and Pressure Sensor Test. Refer to the table be-
low for all tests in the Factory Test.
Testing Machine and Electronic Control Functions
©
