Programming the Audio Step Type
The Audio Step Type is used to alert the user with an audio pat-
tern for a programmed duration when the step is entered. After
selecting the desired Cycle Step number and pressing START
(enter), XXAUdi will appear in the display. Press the NORMAL
40 (∧) or the DELICATES COLD (∨) keypad to scroll through
the options and START (enter) to select a value.
Step
Type Diplay A Display B Values Description
XXAUdi Audio Step Type (XX is step number, step type is
flashing)
En diS XXAU01 EnAbLE, diSAbL, dNod
1, dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming CNP-.
StAtUS XXAU02 PrEWSH, WASH, rinSE1,
rinSE2, rinSE3,
rinSE4, SPin
Status LED: The corresponding LED on the control
will be lit during this step.
NinUtE XXAU03
0-2 Step Minutes
SECond XXAU04
0-59 Step Seconds
AUdioP XXAU05
1-20 Audio Pattern
oUtP 1 XXAU06 oFF, on
External Output #1
oUtP 2 XXAU07 oFF, on
External Output #2
oUtP 3 XXAU08 oFF, on
External Output #3
oUtP 4 XXAU09 oFF, on
External Output #4
Table 21
Programming Control
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
85 Part No. 805405ENR5
