Programming the Soak Step Type
The Soak Step Type allows the owner to program a soak step in a
cycle. The Soak Step Type is identical to the Agitate Step Type
except that it allows hours and minutes to be programmed rather
than minutes and seconds. After selecting the desired Cycle Step
number and pressing START (enter), XXSoAk will appear in the
display. Press the NORMAL 40 (∧) or the DELICATES COLD
(∨) keypad to scroll through the options and START (enter) to se-
lect a value.
Step
Type Diplay A Display B Values Description
XXSoAk Soak Step Type (XX is step number, step type is
flashing)
En diS XXSo01 EnAbLE, diSAbL, dNod
1, dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming CNP-.
StAtUS XXSo02 PrEWSH, WASH, rinSE1,
rinSE2, rinSE3,
rinSE4, SPin
Status LED: The corresponding LED on the control
will be lit during this step.
HoUrS XXSo03
0-255 Step Hours: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
NinUtE XXSo04
0-59 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
HEAt XXAg05 no, tArgEt, MAintA
Heater Temperature
rAtE XXAg06 no, 0.5 - 6.0 (°F/Minute),
0.3 - 3.3 (°C/Minute)
Heat Rate
rotAtE XXSo07
3-255 Motor On Time (seconds)
PAUSE XXSo08
3-255 Motor Off Time (seconds)
SPEEd XXSo09 no rot, LoW Ag, rEg
Ag
10 - 50 RPMs (0.03 - 0.77
G Force)
Rotation Speed
rEvErS XXSo10 rEv on, no rEv
Reversing
drAin1 XXSo11 oFF, on
Drain
rEFiLL XXSo13 oFF, on
Refill: If the water level drops while in the step, wa-
ter will be added until the last set water level set by
the last run fill step is reached.
oUtP 1 XXSo15 oFF, on
External Output #1
oUtP 2 XXSo16 oFF, on
External Output #2
oUtP 3 XXSo17 oFF, on
External Output #3
Table 17 continues...
Programming Control
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
80 Part No. 805405ENR5
