Programming the Agitate Step Type
The Agitate Step Type allows the owner to program the agitate
steps of a cycle. After selecting the desired Cycle Step number
and pressing START (enter), XXAgit will appear in the display.
Press the NORMAL 40 (∧) or the DELICATES COLD (∨) key-
pad to scroll through the options and START (enter) to select a
value.
Step
Type Diplay A Display B Values Description
XXAgit Agitate Step Type (XX is step number, step type is
flashing)
En diS XXAg01 EnAbLE, diSAbL, dNod
1, dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming CNP-.
StAtUS XXAg02 PrEWSH, WASH, rinSE1,
rinSE2, rinSE3,
rinSE4, SPin
Status LED: The corresponding LED on the control
will be lit during this step.
NinUtE XXAg03
0-255 Step Minutes: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
SECond XXAg04
0-59 Step Seconds: If Programmed Cycle Time Display is
enabled and set to a value greater than zero, it will
override this time.
HEAt XXAg05 no, tArgEt, MAintA
Heater Temperature
rAtE XXAg06 no, 0.5 - 6.0 (°F/Minute),
0.3 - 3.3 (°C/Minute)
Heat Rate
rotAtE XXAg07
3-255 Motor On Time (seconds)
PAUSE XXAg08
3-255 Motor Off Time (seconds)
SPEEd XXAg09 no rot, LoW Ag, rEg
Ag
10 - 50 RPMs (0.03 - 0.77
G Force)
Rotation Speed
rEvErS XXAg10 rEv on, no rEv
Reversing
drAin1 XXAg11 oFF, on
Drain
rEFiLL XXAg13 oFF, on
Refill: If the water level drops while in the step, wa-
ter will be added until the last set water level set by
the last run fill step is reached.
oUtP 1 XXAg15 oFF, on
External Output #1
oUtP 2 XXAg16 oFF, on
External Output #2
oUtP 3 XXAg17 oFF, on
External Output #3
Table 16 continues...
