Step

Type Diplay A Display B Values Description

oUtP 4 XXSU22 oFF, on

External Output #4

Table 13

Supply Steps are unique in that they can either be run independ-

ently or be tied to a Fill Step. The following tables are examples

of when the Supply step will be active. All steps below are shown

as enabled, other disabled steps may exist in between shown

steps.

When Supply Step is active with a Fill Step, Supply Step time is

not counted towards total cycle time. Supply steps act as their

own step any time an enabled Fill Step does not directly precede

the enabled Supply Steps.

Steps When active

Step 1 Fill Step

Step 2 Supply Step Active with Step 1

Step 3 Supply Step Active with Step 1

Step 4 Agitate Step

Step 1 Fill Step

Step 2 Agitate Step

Step 3 Supply Step Acts as own step

Step 4 Supply Step Acts as own step

Step 5 Extract Step

Table 14

Steps When active

Step 1 Supply Step Acts as own step

Step 2 Fill Step

Step 3 Supply Step Active with Step 2

Step 4 Agitate Step

Step 1 Fill Step

Step 2 Agitate Step

Step 3 Supply Step Acts as own step

Step 4 Fill Step

Step 5 Supply Step Active with Step 4

Table 15

Programming Control
