Programming the Drain Step Type
The Drain Step Type allows the owner to program the drain steps
of a cycle. After selecting the desired Cycle Step number and
pressing START (enter), XXdrAi will appear in the display.
Press the NORMAL 40 (∧) or the DELICATES COLD (∨) key-
pad to scroll through the options and START (enter) to select a
value.
Step
Type Diplay A Display B Values Description
XXdrAi Drain Step Type (XX is step number, step type is
flashing)
En diS XXdr01 EnAbLE, diSAbL, dNod
1, dNod 2
Step Enable/Disable
Choosing dNod 1 and dNod 2 will enable the step
if the cycle modifier is chosen and set to be enabled
in Cycle Modifier Programming CNP-.
StAtUS XXdr02 PrEWSH, WASH, rinSE1,
rinSE2, rinSE3,
rinSE4, SPin
Status LED: The corresponding LED on the control
will be lit during this step.
rotAtE XXdr06
3-255 Motor On Time (seconds)
PAUSE XXdr07
3-255 Motor Off Time (seconds)
SPEEd XXdr08 no rot, LoW Ag, rEg
Ag, diStrn
15 - 90 RPMs (0.06 - 2.48
G Force)
Rotation Speed
rEvErS XXdr09 rEv on, no rEv
Reversing
oUtP 1 XXdr10 oFF, on
External Output #1
oUtP 2 XXdr11 oFF, on
External Output #2
oUtP 3 XXdr12 oFF, on
External Output #3
oUtP 4 XXdr13 oFF, on
External Output #4
Table 19
