Display Test Mode Comments
drLo or drUL
Door Lock Test When step is entered, control will lock
door and will then check to make sure
door is locked. drLo is displayed if door
is locked. drUL is displayed if door is un-
locked.
CLdE
Cold/Detergent Fill Cold Water Fill valve and Detergent/
Bleach valve are turned on.
HoSF
Hot/Softener Fill Hot Water Fill valve and Softener valve
are turned on.
PrSr
Pressure Sensor Fill This step checks the water level input.
The display shows PrSt, and all water
valves turn on. When the Water Fill Lev-
el is satisfied, the water valves are turned
off. If the Start key is pressed and the
Water Fill level is not satisfied, the con-
trol will not advance to the next cycle
step.
XXC or XXXF
Heater Heater temperature display in degrees
Celcius where XX is temperature or de-
grees Fahrenheit where XXX is tempera-
ture.
oFLo
Overflow Test All water and dispenser valves are turned
on. When the overflow level is reached
the water valves are turned off. If the
START (enter) key is pressed and the
Water Fill level is not satisfied, the con-
trol will not advance to the next cycle
step.
LoAg
Low Agitate Machine enters low agitate.
rEAg
Regular Agitate Machine enters regular agitate.
PUNP or drAi
Pump/Gravity Drain Test Pump is turned on or gravity drain is
opened. The control will not advance to
next step until drum is empty.
RPM speed displayed
XXXX
Spin Test Machine will attempt to spin up to 1200
RPMs.
Table 31 continues...
Testing Machine and Electronic Control Functions
©
Published by permission of the copyright owner -
DO NOT COPY or TRANSMIT
108 Part No. 805405ENR5
