Test Number Diagnostic Mode Display
d 11
Coin Drop #2 Input Test
C2 XX
d 12
Vend Header Present Status Test
CH oP (Open) or CH CL (Closed)
d 13
Start Pulse Test
St XX
d 15
Door Switch Input Test
dr oP, dr CL
d 16
Door Lock Input Test
CLoSE door
d 17
Show Fill Time Test
FL XXX
d 18
Show Drain Time Test
dr XXX
d 19
Temperature Sensor Display Test
XXXF, XXXC, SHort or oPEn
d 22
Out of Balance Switch Input Test
bA oP or bA CL
d 23
External Output Test
ES X or ES Xon
d 24
Water Purge Test
CLoSE, door, PUrgE or FLUSH
d 25
Water Leak Detection Test
PASS, E Ld, E LF or Ld
CLoSE, door
d 26
Water Level Test
L XXX or L XXX.
d 27
DC Bus Voltage Test
XXX.X
d 28
AC Mains Voltage Test
XXX.X
d 29
Machine Configuration #1 Display Test
A XXX
d 30
Machine Configuration #2 Display Test
b XXX
d 31
Machine Configuration #3 Display Test
C XXX
d 32
Machine Configuration #4 Display Test
d XXX
d 33
Machine Configuration #5 Display Test
E XXX
Table 28
Testing Machine and Electronic Control Functions
©
