Chapter 24

Network Statistics

The sections in this chapter explain how to display traffic, error, and history

statistics about the network traffic on the AT-GS950/16 switch and its

ports. This chapter includes the following sections:

 “Overview” on page 320

 “Traffic Comparison Statistics” on page 321

 “Error Group Statistics” on page 325

 “Historical Status Statistics” on page 327

Note

To permanently save your new settings or any changes to the

configuration file, select Save Settings to Flash from the main

menu on the left side of the page.
