AT-GS950/16 Web Interface User Guide
341
Configuration
File Upload
To upload an AT-S114 configuration file from your PC to the switch,
perform the following procedure:
1. Click the Browse button under the Select File field and select the path
and file name.
The path and file name are displayed in the Select File field. See
Figure 139.
Figure 139. Select File Field with Path Location
2. Click the Restore button.
The upload process begins immediately.
If you are uploading a configuration file, the file will be implemented
immediately after upload. A short interruption in network service will
be experienced while the new configuration file is loaded.
If the IP address contained in the new configuration file is different
than the one you currently have in your browser URL, you will loose
connectivity with the AT-S114 Management software on the
AT-GS950/16 switch after the new configuration file is loaded. If this
is the case, you can identify the new IP address by using the ATI
Web Discovery Tool. See“DHCP and ATI Web Discovery Tool” on
page 52 for more information.
3. A message shown in Figure 140 will be displayed indicating that the
upload has been completed. Click OK.
Figure 140. Configuration File Restore Finished Message
