Front and back panels on the GS970M/18PS Switch
Figure 11 illustrates the front panel of the GS970M/18PS Gigabit Ethernet
Switch.
FIGURE 11. GS970M/18PS FRONT PANEL
MAC Address Label
10/100/1000Mbps PoE+ ports
Link/activity/speed LED
PoE status LED
SFP slots
Upper (left), lower (right)
SFP LEDs:
ecofriendly button
SD card slot
MAC address label
Console port
SD/Fault/Power LEDs
