GS9790M Series Switch Installation Guide
71
Powering on the switch
To power on the switch, perform the following procedure:
1. Lift the power cable hook, as shown in Figure 43, on the back of the
switch.
FIGURE 43. LIFTING THE AC POWER CABLE HOOK ON A GS970M SERIES
S
WITCH
2. Plug the power cord into the AC power connector, as shown in
Figure 44, on the back of the switch.
FIGURE 44. PLUGGING IN THE AC POWER CORD ON A GS970M SERIES
S
WITCH
Power cable hook
Power cable hook mount
Power cable
