x530L Series Installation Guide for Virtual Chassis Stacking
41
Table 13. x530L-52GPX Twisted Pair Ports 1 - 48 LED Functions
LED Ports State Description
L/A 1 - 48
Solid Green The port has established a 1Gbps link to a network
device.
Flashing
Green
The port is transmitting or receiving data at 1Gbps.
Solid Amber The port has established a 10Mbps or 100Mbps link
to a network device.
Flashing
Amber
The port is transmitting or receiving data at 10Mbps
or 100 Mbps.
Off Possible causes of this state are:
- The port has not established a link with another
network device.
- The LEDs are turned off. To turn on the LEDs, use
the eco-friendly button.
PoE 1 - 48
Solid Green PD On - The switch is delivering power to a
powered device connected to the port.
Solid Amber PD Error - The switch has shut down PoE on the
port because of a fault condition.
Flashing
Amber
PD Max Current - The switch has detected a
powered device on the port but is not delivering
power to it because doing so would exceed its
available power budget.
OFF No PD - This LED state can result from the following
conditions:
- The port is not connected to a powered device or
the device is powered off.
- The port is disabled in the management software.
- PoE is disabled on the port.
- The LEDs are turned off. To turn on the LEDs, use
the eco-friendly button.
