Copyright © 1996 General Motors Corp. 8–5
WEAR LIMITS AND SPRING DATA
11 7 Modulator valve 6833934 Solid white, 10 0.054 0.49 1.47 0.80 11.90—13.10
orange stripe (1.37) (12.4) (37.3) (20.3) (52.9—58.3)
6838077 Solid yellow 10 0.054 0.49 1.15 0.80 6.01—7.15
(1.37) (12.4) (29.2) (20.3) (26.7—31.8)
6880980 Solid light 10 0.054 0.49 1.36 0.80 9.88—10.92
blue, red stripe (1.37) (12.4) (34.5) (20.3) (43.9—48.6)
23012937 Solid white 9 0.99 0.95 2.27 1.94 9.40—11.40
(2.52) (24.1) (57.7) (49.3) (41.8—50.7)
23012948 Solid white, 10 0.054 0.49 1.47 0.80 11.90—13.10
orange stripe (1.37) (12.4) (37.3) (20.3) (52.9—58.3)
11 14 Third clutch trimmer valve 6833938 Solid yellow 12.5 0.080 0.94 2.96 1.10 15.95—17.65
(2.03) (23.9) (75.2) (27.9) (70.9—78.5)
6833945 Solid light 7.4 0.092 0.93 2.27 1.94 9.40—11.40
blue (2.34) (23.6) (57.7) (49.3) (41.8—50.7)
6880045 Solid orange 10 0.099 0.94 2.18 1.94 6.20—7.40
(2.51) (23.9) (55.4) (49.3) (27.6—32.9)
23012937 Solid white 9 0.099 0.95 2.27 1.10 34.80—38.80
(2.51) (24.1) (57.7) (27.9) (154.8—172.6)
23017086 Solid white, 8.5 0.105 0.95 2.21 1.94 11.0—13.4
black stripe (2.67) (24.1) (56.1) (49.3) (48.9—59.6)
23018733 One end 11.3 0.078 0.94 2.98 1.94 8.30—10.30
orange (1.98) (23.9) (75.7) (49.3) (36.9—45.8)
11 NI* Third clutch trimmer valve 6885166 Orange, 9.6 0.092 0.69 1.69 1.10 32.60—39.80
(inner) (earlier models) white stripe (2.34) (17.53) (42.9) (27.9) (145.0—177.0)
(inner spring no longer used) 23011987 Solid red, 11 0.072 0.68 1.52 1.10 7.20—8.80
orange stripe (1.83) (17.3) (38.6) (27.9) (32.0—39.1)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
*NI — Not Illustrated
