8–6 Copyright © 1996 General Motors Corp.
AT 500, AT 1500 SERIES AUTOMATIC TRANSMISSIONS
11 18 First clutch trimmer 6833945 Solid light 7.4
0.092
(2.34)
0.93 2.27 1.94 9.40—11.40
valve (outer) blue (23.6) (57.7) (49.3) (41.8—50.7)
6838839 Solid purple, 8 0.092 0.93 1.95 1.10 22.4—26.4
orange stripe (2.34) (23.6) (49.5) (27.9) (99.6—117.4)
6839271 Solid white, 10 0.102 0.94 2.56 1.94 20.00—22.00
yellow stripe (2.59) (23.9) (65.0) (49.3) (89.0—97.9)
6880045 Solid orange 10 0.099 0.94 2.18 1.94 6.20—7.40
(2.51) (23.9) (55.4) (49.3) (27.6—32.9)
23012937 Solid white 9 0.099 0.95 2.27 1.10 34.80—38.80
(2.51) (24.1) (57.7) (27.9) (154.8—172.6)
11 19 Second clutch trimmer 6839102 Solid red 8.5 0.092 0.72 1.68 1.10 32.60—39.80
valve (inner) (2.34) (18.3) (42.7) (27.9) (145.0—177.0)
6880118 Blue, 8.5 0.091 0.69 1.45 1.10 21.70—25.30
white stripe (2.31) (17.53) (36.8) (27.9) (96.5—112.5)
6880274 Solid yellow, 9.6 0.092 0.69 1.69 1.10 32.60—39.80
blue stripe (2.34) (17.5) (42.9) (27.9) (145.0—177.0)
6884701 Solid orange 9.6 0.092 0.69 1.69 1.10 32.60—39.80
(2.34) (17.5) (42.9) (27.9) (145.0—177.0)
6885166 Solid orange, 9.6 0.091 0.72 1.69 1.10 32.60—39.80
white stripe (2.31) (18.3) (42.9) (27.9) (145.0—177.0)
11 23 Second clutch trimmer 6833940 Solid orange, 8.5 0.121 0.95 2.38 1.94 29.00—35.00
valve (outer) yellow stripe (3.07) (24.1) (60.5) (49.3) (129.0—155.7)
6837692 Yellow 9.5 0.101 0.94 2.33 1.20 37.80—41.88
(2.57) (23.88) (59.2) (30.5) (168.1—185.9)
6838532 Solid white 8.5 0.121 0.95 2.10 1.94 10.50—15.50
(3.07) (24.1) (53.3) (49.3) (46.7—68.9)
6839102 Solid red 8.5 0.092 0.72 1.68 1.10 32.60—39.80
(2.34) (18.3) (42.7) (27.9) (145.0—177.0)
6839271 Solid white, 10 0.102 0.94 2.56 1.94 20.00–22.00
yellow stripe (2.59) (23.9) (65.0) (49.3) (89.0–97.9)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
