WEAR LIMITS AND SPRING DATA

11 23 Second clutch trimmer 6883300 Solid light 10 0.082 0.69 1.95 1.10 31.20–37.20

valve (outer)

(cont’d)

green, white (2.08) (17.5) (49.5) (27.9) (138.8–165.5)

6885047 Solid light 10 0.098 0.94 2.57 1.94 16.10–19.70

green (2.49) (23.9) (65.3) (49.3) (71.6–87.6)

6885164 Solid white, 8.5 0.121 0.95 2.10 1.94 10.50–15.50

orange stripe (3.07) (24.1) (53.3) (49.3) (46.7–68.9)

23011988 Solid yellow, 8.5 0.092 0.94 2.31 1.10 29.0–32.2

orange stripe (2.34) (23.88) (58.7) (27.9) (129.0–143.2)

23012937 Solid white 9 0.099 0.95 2.27 1.10 34.80–38.80

(2.51) (24.1) (57.7) (27.9) (154.8–172.6)

23017086 Solid white, 8.5 0.105 0.95 2.21 1.94 11.00–13.40

black stripe (2.67) (24.1) (56.1) (49.3) (48.9–59.6)

11 24 Second clutch trimmer 6839102 Solid red 8.5 0.092 0.72 1.68 1.10 32.60–39.80

valve (inner) (2.34) (18.3) (42.7) (27.9) (145.0–177.0)

6880045 Orange 10 0.099 0.94 2.18 1.94 6.20–7.40

(2.51) (23.88) (55.4) (49.3) (27.6–32.9)

6883300 Solid lt. green, 10 0.082 0.69 1.95 1.10 31.20–37.20

white stripe (2.08) (17.5) (49.5) (27.9) (138.8–165.5)

6885166 Solid orange, 9.6 0.091 0.72 1.69 1.10 32.60–39.80

white stripe (2.31) (18.3) (42.9) (27.9) (145.0–177.0)

23013908 Solid white 10 0.080 0.69 1.80 1.10 21.50–23.70

(2.03) (17.53) (45.7) (27.9) (95.5–105.5)

11 27 Trim boost accumulator 23013744 Solid light blue, 13 0.060 0.62 2.61 0.95 15.50–17.10

valve white stripe (1.52) (15.7) (66.3) (24.1) (68.9–76.1)

23013054 Solid orange, 15 0.054 0.62 2.72 0.90 8.70–10.70

light blue stripe (1.37) (15.7) (69.1) (22.9) (38.7–47.6)

11 31 Fourth clutch trimmer 6837692 Yellow 9.5 0.101 0.94 2.33 1.20 37.80–41.80

valve (outer) (2.57) (23.88) (59.2) (30.5) (168.1–185.9)

6839271 Solid white, 10 0.102 0.94 2.56 1.94 20.00–22.00

yellow stripe (2.59) (23.9) (65.0) (49.3) (89.0–97.9)

Table 8–2. Spring Data

(Cont’d)

Spring Free

Color No. Wire dia OD Length Length Under Load

Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
