8–8 Copyright © 1996 General Motors Corp.
AT 500, AT 1500 SERIES AUTOMATIC TRANSMISSIONS
11 31 Fourth clutch trimmer 6880045 Orange 10 0.099 0.94 2.18 1.94 6.20–7.40
valve (outer)
(cont’d)
(2.51) (23.88) (55.4) (49.3) (27.6–32.9)
23012937 Solid white 9 0.099 0.95 2.27 1.94 9.40–11.40
(2.52) (24.1) (57.7) (49.3) (41.8–50.7)
11 32 Fourth clutch trimmer 6880118 Solid light blue, 8.5 0.091 0.69 1.42 1.10 20.70–25.30
valve (inner) white stripe (2.31) (17.5) (36.1) (27.9) (92.1–112.5)
11 38 2–3 relay valve 6832462 Solid red 11 0.072 0.69 2.18 1.20 16.20–19.80
(1.83) (17.5) (55.4) (30.5) (72.1–88.1)
11 41 1–2 relay valve 6834528 Solid light blue, 11 0.072 0.68 1.52 1.10 7.20–8.80
yellow stripe (1.83) (17.3) (38.6) (27.9) (32.0–39.1)
11 44 Priority valve 6835729 Solid white, 11 0.054 0.38 1.17 0.94 8.15–9.15
yellow stripe (1.37) (9.7) (29.7) (23.9) (36.3–40.7)
11 47 Hold regulator valve 6836784 Solid yellow 13 0.041 0.40 1.90 1.15 5.93–6.17
(1.04) (10.2) (48.3) (29.2) (26.4–27.4)
6836785 Solid white 14 0.041 0.40 2.01 1.15 6.22–6.48
(1.04) (10.2) (51.1) (29.2) (27.7–28.8)
6836976 Solid white, 14 0.044 0.40 1.85 1.15 6.91–7.19
yellow stripe (1.12) (10.2) (47.0) (29.2) (30.7–32.0)
6836977 Orange 16 0.047 0.40 1.85 1.15 7.79–8.11
(1.19) (10.16) (47.0) (29.2) (34.7–36.1)
6837539 Solid light blue, 11 0.041 0.40 1.72 1.15 5.44–5.66
white stripe (1.04) (10.2) (43.7) (29.2) (24.2–25.2)
6837541 Solid yellow, 14 0.044 0.40 1.82 1.15 6.61–6.89
light blue stripe (1.12) (10.2) (46.2) (29.2) (29.4–30.6)
6837952 Solid light 14 0.044 0.40 1.87 1.15 7.10–7.40
green (1.12) (10.2) (47.5) (29.2) (31.6–32.9)
6837953 Solid light 14 0.044 0.40 1.91 1.15 7.46–7.76
blue (1.12) (10.2) (48.5) (29.2) (33.2–34.5)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
