Copyright © 1996 General Motors Corp. 8–9
WEAR LIMITS AND SPRING DATA
11 56 1–2 shift valve 6833935 Solid blue 9 0.054 0.64 2.17 1.15 8.60–9.10
(1.37) (16.3) (55.1) (29.2) (38.3–40.5)
6833941 Solid blue, 13.5 0.062 0.64 2.15 1.15 9.35–9.85
white stripe (1.57) (16.3) (54.6) (29.2) (41.6–43.8)
6833942 Solid white 12 0.054 0.64 2.50 1.15 7.85–8.35
(1.37) (16.3) (63.5) (29.2) (34.9–37.1)
6834576 Solid orange, 12 0.054 0.64 2.39 1.15 7.18–7.68
yellow stripe (1.37) (16.3) (60.7) (29.2) (31.9–34.2)
6837454 Solid yellow 9 0.056 0.64 1.98 1.15 8.22–8.72
(1.42) (16.3) (50.3) (29.2) (36.6–38.8)
6837882 No color code 8.5 0.054 0.73 1.74 0.81 5.02–6.14
(1.37) (18.5) (44.2) (20.6) (22.3–27.3)
6881061 Solid light blue, 12 0.054 0.64 2.55 1.15 8.10–8.70
orange stripe (1.37) (16.3) (64.8) (29.2) (36.0–38.7)
23012946 Solid orange, 12 0.054 0.64 2.39 1.15 7.18–7.68
yellow stripe (1.37) (16.3) (60.7) (29.2) (31.9–34.2)
23017028 Solid yellow, 12 0.054 0.64 2.65 1.15 8.65–9.35
black stripe (1.37) (16.3) (67.3) (29.2) (38.5–41.6)
23017031 Solid orange, 12 0.054 0.64 2.36 1.15 6.95–7.55
black stripe (1.37) (16.3) (59.9) (29.2) (30.9–33.6)
23017045 Solid light blue, 12 0.054 0.64 2.40 1.15 7.20–7.80
purple stripe (1.37) (16.3) (61.0) (29.2) (32.0–34.7)
23017047 Solid orange, 12 0.054 0.64 2.48 1.15 7.70–8.30
purple stripe (1.37) (16.3) (63.0) (29.2) (34.3–36.9)
23017048 Solid white, 12 0.054 0.64 2.61 1.15 8.45–9.05
purple stripe (1.37) (16.3) (66.3) (29.2) (37.6–40.3)
23018388 Solid white, 12 0.054 0.64 2.53 1.15 7.95–8.55
one end red (1.37) (16.3) (64.3) (29.2) (35.4–38.0)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
