8–10 Copyright © 1996 General Motors Corp.
AT 500, AT 1500 SERIES AUTOMATIC TRANSMISSIONS
11 62 2–3 shift valve 6833935 Solid blue 9 0.054 0.64 2.17 1.15 8.60–9.10
(1.37) (16.3) (55.1) (29.2) (38.3–40.5)
6833941 Solid blue, 13.5 0.062 0.64 2.15 1.15 9.35–9.85
white stripe (1.57) (16.3) (54.6) (29.2) (41.6–43.8)
6833942 Solid white 12 0.054 0.64 2.50 1.15 7.85–8.35
(1.37) (16.3) (63.5) (29.2) (34.9–37.1)
6834902 Solid orange 13 0.059 0.64 2.41 1.15 9.95–10.45
(1.50) (16.3) (61.2) (29.2) (44.3–46.5)
6835310 Solid green 13 0.059 0.64 2.51 1.15 10.75–11.25
(1.50) (16.3) (63.8) (29.2) (47.8–50.0)
6837454 Solid yellow 9 0.056 0.64 1.98 1.15 8.22–8.72
(1.42) (16.3) (50.3) (29.2) (36.6–38.8)
6880991 Solid light 12 0.054 0.64 2.75 1.15 9.25–9.95
blue, red stripe (1.37) (16.3) (69.9) (29.2) (41.1–44.3)
6880992 Solid white, 12 0.054 0.64 2.85 1.15 9.85–10.55
red stripe (1.37) (16.3) (72.4) (29.2) (43.8–46.9)
6881061 Solid light blue, 12 0.054 0.64 2.55 1.15 8.10–8.70
orange stripe (1.37) (16.3) (64.8) (29.2) 36.0–38.7)
6883665 Solid white, 12 0.054 0.64 2.82 1.15 9.65–10.35
green stripe (1.37) (16.3) (71.6) (29.2) (42.9–46.0)
23012950 Solid white, 12 0.054 0.64 2.90 1.15 10.15–10.85
blue stripe (1.37) (16.3) (73.7) (29.2) (45.1–48.3)
23012951 Solid orange, 12 0.054 0.64 2.98 1.15 10.60–11.40
green stripe (1.37) (16.3) (75.7) (29.2) (47.2–50.7)
23012952 Solid orange, 9 0.054 0.64 2.17 1.15 8.60–9.10
red stripe (1.37) (16.3) (55.1) (29.2) (38.3–40.5)
23012954 Solid yellow, 13 0.059 0.64 2.51 1.15 10.75–11.25
green stripe (1.50) (16.3) (63.8) (29.2) (47.8–50.0)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
To Next Page
