Copyright © 1996 General Motors Corp. 8–11
WEAR LIMITS AND SPRING DATA
11 62 2–3 shift valve
(cont’d)
23012955 Solid green, 13.5 0.062 0.64 2.15 1.15 9.35–9.85
blue stripe (1.57) (16.3) (54.6) (29.2) (41.6–43.8)
23012956 Solid red, 13 0.059 0.64 2.41 1.15 9.95–10.45
blue stripe (1.50) (16.3) (61.2) (29.2) (44.3–46.5)
23013271 Blue, 12 0.054 0.64 2.73 1.15 9.15–9.85
yellow stripe (1.37) (16.26) (69.3) (29.2) (40.7–43.8)
23013273 Solid orange, 12 0.054 0.64 2.65 1.15 8.65–9.35
yellow stripe (1.37) (16.3) (67.3) (29.2) (38.5–41.6)
23017028 Solid yellow, 12 0.054 0.64 2.65 1.15 8.65–9.35
black stripe (1.37) (16.3) (67.3) (29.2) (38.5–41.6)
23045295 Solid orange, 13.8 0.056 0.64 2.98 1.15 10.60–11.40
one end white (1.42) (16.3) (75.7) (29.2) (47.2–50.7)
29503530 Gray 12 0.054 0.64 2.48 1.15 7.9–8.3
(1.37) (16.26) (63.0) (29.2) (35.1–36.9)
11 68 3–4 shift valve 6833935 Solid blue 9 0.054 0.64 2.17 1.15 8.60–9.10
(1.37) (16.3) (55.1) (29.2) (38.3–40.5)
6833941 Solid blue, 13.5 0.062 0.64 2.15 1.15 9.35–9.85
white stripe (1.57) (16.3) (54.6) (29.2) (41.6–43.8)
6833942 Solid white 12 0.054 0.64 2.50 1.15 7.85–8.35
(1.37) (16.3) (63.5) (29.2) (34.9–37.1)
6834576 Solid orange, 12 0.054 0.64 2.39 1.15 7.18–7.68
yellow stripe (1.37) (16.3) (60.7) (29.2) (31.9–34.2)
6834902 Solid orange 13 0.059 0.64 2.41 1.15 9.95–10.45
(1.50) (16.3) (61.2) (29.2) (44.3–46.5)
6837454 Solid yellow 9 0.056 0.64 1.98 1.15 8.22–8.72
(1.42) (16.3) (50.3) (29.2) (36.6–38.8)
6880991 Solid light 12 0.054 0.64 2.75 1.15 9.25–9.95
blue, red stripe (1.37) (16.3) (69.9) (29.2) (41.1–44.3)
6880992 Solid white, 12 0.054 0.64 2.85 1.15 9.85–10.55
red stripe (1.37) (16.3) (72.4) (29.2) (43.8–46.9)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
