8–12 Copyright © 1996 General Motors Corp.
AT 500, AT 1500 SERIES AUTOMATIC TRANSMISSIONS
11 68 3–4 shift valve
(cont’d)
6881061 Solid light blue, 12 0.054 0.64 2.55 1.15 8.10–8.70
orange stripe (1.37) (16.3) (64.8) (29.2) (36.0–38.7)
6884947 No color 12 0.054 0.64 2.86 1.15 9.90–10.60
(1.37) (16.26) (72.6) (29.2) (44.0–47.2)
23012946 Solid orange, 12 0.054 0.64 2.39 1.15 7.18–7.68
yellow stripe (1.37) (16.3) (60.7) (29.2) (31.9–34.2)
23012952 Solid orange, 9 0.054 0.64 2.17 1.15 8.60–9.10
red stripe (1.37) (16.3) (55.1) (29.2) (38.3–40.5)
23012955 Solid green, 13.5 0.062 0.64 2.15 1.15 9.35–9.85
blue stripe (1.57) (16.3) (54.6) (29.2) (41.6–43.8)
23012956 Solid red, 13 0.059 0.64 2.41 1.15 9.95–10.45
blue stripe (1.50) (16.3) (61.2) (29.2) (44.3–46.5)
23013267 Solid yellow 12 0.054 0.64 2.57 1.15 8.20–8.80
(1.37) (16.3) (65.3) (29.2) (36.5–39.1)
23013269 Solid orange 12 0.054 0.64 2.69 1.15 8.90–9.60
(1.37) (16.3) (68.3) (29.2) (39.6–42.7)
23013271 Blue, 12 0.054 0.64 2.36 1.15 6.95–7.55
yellow stripe (1.37) (16.26) (59.9) (29.2) (30.9–33.6)
23017047 Solid orange, 12 0.054 0.64 2.48 1.15 7.70–8.30
purple stripe (1.37) (16.26) (63.0) (29.2) (34.3–36.9)
29503530 Gray 12 0.054 0.64 2.48 1.15 7.9–8.3
(1.37) (16.26) (63.0) (29.2) (35.1–36.9)
11 73 3–4 relay valve 6832462 Solid red 11 0.072 0.69 2.18 1.20 16.20–19.80
(1.83) (17.5) (55.4) (30.5) (72.1–88.1)
11 77 Trimmer regulator valve 6834527 Solid light 14 0.047 0.50 1.87 1.14 4.25–4.75
blue, red stripe (1.19) (12.7) (47.5) (29.0) (18.9–21.1)
6880246 Solid light 13 0.041 0.46 1.81 0.89 4.25–4.75
blue (1.04) (11.7) (46.0) (22.6) (18.9–21.1)
Table 8–2. Spring Data
(Cont’d)
Spring Free
Color No. Wire dia OD Length Length Under Load
Foldout Ref Spring Part No. Code Coils in. (mm) in. (mm) in. (mm) in. (mm) lb (N)
