DE1-SoC User Manual
27
www.terasic.com
March 14, 2014
Table 3-9 Pin Assignment of 7-segment Displays
Signal Name
FPGA Pin No.
Description
I/O Standard
HEX0[0]
PIN_AE26
Seven Segment Digit 0[0]
3.3V
HEX0[1]
PIN_AE27
Seven Segment Digit 0[1]
3.3V
HEX0[2]
PIN_AE28
Seven Segment Digit 0[2]
3.3V
HEX0[3]
PIN_AG27
Seven Segment Digit 0[3]
3.3V
HEX0[4]
PIN_AF28
Seven Segment Digit 0[4]
3.3V
HEX0[5]
PIN_AG28
Seven Segment Digit 0[5]
3.3V
HEX0[6]
PIN_AH28
Seven Segment Digit 0[6]
3.3V
HEX1[0]
PIN_AJ29
Seven Segment Digit 1[0]
3.3V
HEX1[1]
PIN_AH29
Seven Segment Digit 1[1]
3.3V
HEX1[2]
PIN_AH30
Seven Segment Digit 1[2]
3.3V
HEX1[3]
PIN_AG30
Seven Segment Digit 1[3]
3.3V
HEX1[4]
PIN_AF29
Seven Segment Digit 1[4]
3.3V
HEX1[5]
PIN_AF30
Seven Segment Digit 1[5]
3.3V
HEX1[6]
PIN_AD27
Seven Segment Digit 1[6]
3.3V
HEX2[0]
PIN_AB23
Seven Segment Digit 2[0]
3.3V
HEX2[1]
PIN_AE29
Seven Segment Digit 2[1]
3.3V
HEX2[2]
PIN_AD29
Seven Segment Digit 2[2]
3.3V
HEX2[3]
PIN_AC28
Seven Segment Digit 2[3]
3.3V
HEX2[4]
PIN_AD30
Seven Segment Digit 2[4]
3.3V
HEX2[5]
PIN_AC29
Seven Segment Digit 2[5]
3.3V
HEX2[6]
PIN_AC30
Seven Segment Digit 2[6]
3.3V
HEX3[0]
PIN_AD26
Seven Segment Digit 3[0]
3.3V
HEX3[1]
PIN_AC27
Seven Segment Digit 3[1]
3.3V
HEX3[2]
PIN_AD25
Seven Segment Digit 3[2]
3.3V
HEX3[3]
PIN_AC25
Seven Segment Digit 3[3]
3.3V
HEX3[4]
PIN_AB28
Seven Segment Digit 3[4]
3.3V
HEX3[5]
PIN_AB25
Seven Segment Digit 3[5]
3.3V
HEX3[6]
PIN_AB22
Seven Segment Digit 3[6]
3.3V
HEX4[0]
PIN_AA24
Seven Segment Digit 4[0]
3.3V
HEX4[1]
PIN_Y23
Seven Segment Digit 4[1]
3.3V
HEX4[2]
PIN_Y24
Seven Segment Digit 4[2]
3.3V
HEX4[3]
PIN_W22
Seven Segment Digit 4[3]
3.3V
HEX4[4]
PIN_W24
Seven Segment Digit 4[4]
3.3V
HEX4[5]
PIN_V23
Seven Segment Digit 4[5]
3.3V
HEX4[6]
PIN_W25
Seven Segment Digit 4[6]
3.3V
HEX5[0]
PIN_V25
Seven Segment Digit 5[0]
3.3V
HEX5[1]
PIN_AA28
Seven Segment Digit 5[1]
3.3V
HEX5[2]
PIN_Y27
Seven Segment Digit 5[2]
3.3V
HEX5[3]
PIN_AB27
Seven Segment Digit 5[3]
3.3V
HEX5[4]
PIN_AB26
Seven Segment Digit 5[4]
3.3V
HEX5[5]
PIN_AA26
Seven Segment Digit 5[5]
3.3V
HEX5[6]
PIN_AA25
Seven Segment Digit 5[6]
3.3V
