The following hardware is provided on the board:
 FPGA
 Altera Cyclone® V SE 5CSEMA5F31C6N device
 Altera serial configuration device – EPCQ256
 USB-Blaster II onboard for programming; JTAG Mode
 64MB SDRAM (16-bit data bus)
 4 push-buttons
 10 slide switches
 10 red user LEDs
 Six 7-segment displays
 Four 50MHz clock sources from the clock generator
 24-bit CD-quality audio CODEC with line-in, line-out, and microphone-in jacks
 VGA DAC (8-bit high-speed triple DACs) with VGA-out connector
 TV decoder (NTSC/PAL/SECAM) and TV-in connector
 PS/2 mouse/keyboard connector
 IR receiver and IR emitter
 Two 40-pin expansion header with diode protection
 A/D converter, 4-pin SPI interface with FPGA
 HPS (Hard Processor System)
 800MHz Dual-core ARM Cortex-A9 MPCore processor
 1GB DDR3 SDRAM (32-bit data bus)
 1 Gigabit Ethernet PHY with RJ45 connector
 2-port USB Host, normal Type-A USB connector
 Micro SD card socket
 Accelerometer (I2C interface + interrupt)
 UART to USB, USB Mini-B connector
 Warm reset button and cold reset button
 One user button and one user LED
 LTC 2x7 expansion header
2
2
.
.
2
2
B
B
l
l
o
o
c
c
k
k
D
D
i
i
a
a
g
g
r
r
a
a
m
m
o
o
f
f
t
t
h
h
e
e
D
D
E
E
1
1
-
-
S
S
o
o
C
C
B
B
o
o
a
a
r
r
d
d
Figure 2-3 is the block diagram of the board. All the connections are established through the
Cyclone V SoC FPGA device to provide maximum flexibility for users. Users can configure the
FPGA to implement any system design.
