Chapter 4
DE1-SoC System
Builder
This chapter describes how users can create a custom design project with the tool named DE1-SoC
System Builder.
4
4
.
.
1
1
I
I
n
n
t
t
r
r
o
o
d
d
u
u
c
c
t
t
i
i
o
o
n
n
The DE1-SoC System Builder is a Windows-based utility. It is designed to help users create a
Quartus II project for DE1-SoC within minutes. The generated Quartus II project files include:
 Quartus II project file (.qpf)
 Quartus II setting file (.qsf)
 Top-level design file (.v)
 Synopsis design constraints file (.sdc)
 Pin assignment document (.htm)
The above files generated by the DE1-SoC System Builder can also prevent occurrence of situations
that are prone to compilation error when users manually edit the top-level design file or place pin
assignment. The common mistakes that users encounter are:
 Board is damaged due to incorrect bank voltage setting or pin assignment.
 Board is malfunctioned because of wrong device chosen, declaration of pin location or
direction is incorrect or forgotten.
 Performance degradation due to improper pin assignment.
4
4
.
.
2
2
D
D
e
e
s
s
i
i
g
g
n
n
F
F
l
l
o
o
w
w
This section provides an introduction to the design flow of building a Quartus II project for
DE1-SoC under the DE1-SoC System Builder. The design flow is illustrated in Figure 4-1.
