Altera DE1-SoC - Page 30

DE1-SoC User Manual
29
www.terasic.com
March 14, 2014
GPIO_0 [4]
PIN_AK16
GPIO Connection 0[4]
3.3V
GPIO_0 [5]
PIN_AK18
GPIO Connection 0[5]
3.3V
GPIO_0 [6]
PIN_AK19
GPIO Connection 0[6]
3.3V
GPIO_0 [7]
PIN_AJ19
GPIO Connection 0[7]
3.3V
GPIO_0 [8]
PIN_AJ17
GPIO Connection 0[8]
3.3V
GPIO_0 [9]
PIN_AJ16
GPIO Connection 0[9]
3.3V
GPIO_0 [10]
PIN_AH18
GPIO Connection 0[10]
3.3V
GPIO_0 [11]
PIN_AH17
GPIO Connection 0[11]
3.3V
GPIO_0 [12]
PIN_AG16
GPIO Connection 0[12]
3.3V
GPIO_0 [13]
PIN_AE16
GPIO Connection 0[13]
3.3V
GPIO_0 [14]
PIN_AF16
GPIO Connection 0[14]
3.3V
GPIO_0 [15]
PIN_AG17
GPIO Connection 0[15]
3.3V
GPIO_0 [16]
PIN_AA18
GPIO Connection 0[16]
3.3V
GPIO_0 [17]
PIN_AA19
GPIO Connection 0[17]
3.3V
GPIO_0 [18]
PIN_AE17
GPIO Connection 0[18]
3.3V
GPIO_0 [19]
PIN_AC20
GPIO Connection 0[19]
3.3V
GPIO_0 [20]
PIN_AH19
GPIO Connection 0[20]
3.3V
GPIO_0 [21]
PIN_AJ20
GPIO Connection 0[21]
3.3V
GPIO_0 [22]
PIN_AH20
GPIO Connection 0[22]
3.3V
GPIO_0 [23]
PIN_AK21
GPIO Connection 0[23]
3.3V
GPIO_0 [24]
PIN_AD19
GPIO Connection 0[24]
3.3V
GPIO_0 [25]
PIN_AD20
GPIO Connection 0[25]
3.3V
GPIO_0 [26]
PIN_AE18
GPIO Connection 0[26]
3.3V
GPIO_0 [27]
PIN_AE19
GPIO Connection 0[27]
3.3V
GPIO_0 [28]
PIN_AF20
GPIO Connection 0[28]
3.3V
GPIO_0 [29]
PIN_AF21
GPIO Connection 0[29]
3.3V
GPIO_0 [30]
PIN_AF19
GPIO Connection 0[30]
3.3V
GPIO_0 [31]
PIN_AG21
GPIO Connection 0[31]
3.3V
GPIO_0 [32]
PIN_AF18
GPIO Connection 0[32]
3.3V
GPIO_0 [33]
PIN_AG20
GPIO Connection 0[33]
3.3V
GPIO_0 [34]
PIN_AG18
GPIO Connection 0[34]
3.3V
GPIO_0 [35]
PIN_AJ21
GPIO Connection 0[35]
3.3V
GPIO_1[0]
PIN_AB17
GPIO Connection 1[0]
3.3V
GPIO_1[1]
PIN_AA21
GPIO Connection 1[1]
3.3V
GPIO_1 [2]
PIN_AB21
GPIO Connection 1[2]
3.3V
GPIO_1 [3]
PIN_AC23
GPIO Connection 1[3]
3.3V
GPIO_1 [4]
PIN_AD24
GPIO Connection 1[4]
3.3V
GPIO_1 [5]
PIN_AE23
GPIO Connection 1[5]
3.3V
GPIO_1 [6]
PIN_AE24
GPIO Connection 1[6]
3.3V
GPIO_1 [7]
PIN_AF25
GPIO Connection 1[7]
3.3V
GPIO_1 [8]
PIN_AF26
GPIO Connection 1[8]
3.3V
GPIO_1 [9]
PIN_AG25
GPIO Connection 1[9]
3.3V
GPIO_1[10]
PIN_AG26
GPIO Connection 1[10]
3.3V
GPIO_1 [11]
PIN_AH24
GPIO Connection 1[11]
3.3V
