DE1-SoC User Manual
47
www.terasic.com
March 14, 2014
HPS_DDR3_A[6]
PIN_F29
HPS DDR3 Address[6]
SSTL-15 Class I
HPS_DDR3_A[7]
PIN_E28
HPS DDR3 Address[7]
SSTL-15 Class I
HPS_DDR3_A[8]
PIN_H27
HPS DDR3 Address[8]
SSTL-15 Class I
HPS_DDR3_A[9]
PIN_G26
HPS DDR3 Address[9]
SSTL-15 Class I
HPS_DDR3_A[10]
PIN_D29
HPS DDR3 Address[10]
SSTL-15 Class I
HPS_DDR3_A[11]
PIN_C30
HPS DDR3 Address[11]
SSTL-15 Class I
HPS_DDR3_A[12]
PIN_B30
HPS DDR3 Address[12]
SSTL-15 Class I
HPS_DDR3_A[13]
PIN_C29
HPS DDR3 Address[13]
SSTL-15 Class I
HPS_DDR3_A[14]
PIN_H25
HPS DDR3 Address[14]
SSTL-15 Class I
HPS_DDR3_BA[0]
PIN_E29
HPS DDR3 Bank Address[0]
SSTL-15 Class I
HPS_DDR3_BA[1]
PIN_J24
HPS DDR3 Bank Address[1]
SSTL-15 Class I
HPS_DDR3_BA[2]
PIN_J23
HPS DDR3 Bank Address[2]
SSTL-15 Class I
HPS_DDR3_CAS_n
PIN_E27
DDR3 Column Address Strobe
SSTL-15 Class I
HPS_DDR3_CKE
PIN_L29
HPS DDR3 Clock Enable
SSTL-15 Class I
HPS_DDR3_CK_n
PIN_L23
HPS DDR3 Clock
Differential 1.5-V SSTL Class I
HPS_DDR3_CK_p
PIN_M23
HPS DDR3 Clock p
Differential 1.5-V SSTL Class I
HPS_DDR3_CS_n
PIN_H24
HPS DDR3 Chip Select
SSTL-15 Class I
HPS_DDR3_DM[0]
PIN_K28
HPS DDR3 Data Mask[0]
SSTL-15 Class I
HPS_DDR3_DM[1]
PIN_M28
HPS DDR3 Data Mask[1]
SSTL-15 Class I
HPS_DDR3_DM[2]
PIN_R28
HPS DDR3 Data Mask[2]
SSTL-15 Class I
HPS_DDR3_DM[3]
PIN_W30
HPS DDR3 Data Mask[3]
SSTL-15 Class I
HPS_DDR3_DQ[0]
PIN_K23
HPS DDR3 Data[0]
SSTL-15 Class I
HPS_DDR3_DQ[1]
PIN_K22
HPS DDR3 Data[1]
SSTL-15 Class I
HPS_DDR3_DQ[2]
PIN_H30
HPS DDR3 Data[2]
SSTL-15 Class I
HPS_DDR3_DQ[3]
PIN_G28
HPS DDR3 Data[3]
SSTL-15 Class I
HPS_DDR3_DQ[4]
PIN_L25
HPS DDR3 Data[4]
SSTL-15 Class I
HPS_DDR3_DQ[5]
PIN_L24
HPS DDR3 Data[5]
SSTL-15 Class I
HPS_DDR3_DQ[6]
PIN_J30
HPS DDR3 Data[6]
SSTL-15 Class I
HPS_DDR3_DQ[7]
PIN_J29
HPS DDR3 Data[7]
SSTL-15 Class I
HPS_DDR3_DQ[8]
PIN_K26
HPS DDR3 Data[8]
SSTL-15 Class I
HPS_DDR3_DQ[9]
PIN_L26
HPS DDR3 Data[9]
SSTL-15 Class I
HPS_DDR3_DQ[10]
PIN_K29
HPS DDR3 Data[10]
SSTL-15 Class I
HPS_DDR3_DQ[11]
PIN_K27
HPS DDR3 Data[11]
SSTL-15 Class I
HPS_DDR3_DQ[12]
PIN_M26
HPS DDR3 Data[12]
SSTL-15 Class I
HPS_DDR3_DQ[13]
PIN_M27
HPS DDR3 Data[13]
SSTL-15 Class I
HPS_DDR3_DQ[14]
PIN_L28
HPS DDR3 Data[14]
SSTL-15 Class I
HPS_DDR3_DQ[15]
PIN_M30
HPS DDR3 Data[15]
SSTL-15 Class I
HPS_DDR3_DQ[16]
PIN_U26
HPS DDR3 Data[16]
SSTL-15 Class I
HPS_DDR3_DQ[17]
PIN_T26
HPS DDR3 Data[17]
SSTL-15 Class I
HPS_DDR3_DQ[18]
PIN_N29
HPS DDR3 Data[18]
SSTL-15 Class I
HPS_DDR3_DQ[19]
PIN_N28
HPS DDR3 Data[19]
SSTL-15 Class I
HPS_DDR3_DQ[20]
PIN_P26
HPS DDR3 Data[20]
SSTL-15 Class I
HPS_DDR3_DQ[21]
PIN_P27
HPS DDR3 Data[21]
SSTL-15 Class I
HPS_DDR3_DQ[22]
PIN_N27
HPS DDR3 Data[22]
SSTL-15 Class I
