RS2310002 Rev. 1 34
• Do not lift door by handle. Glass can break.
• Only push hinges closed once oven door is
removed if necessary. Use both hands when
closing hinge. Hinge snaps closed.
Replacing Oven Light
WARNING
To avoid risk of burns or electrical shock, disconnect
electrical supply to range before changing light bulb.
• Before replacing light bulb make sure bulb is cool.
• Wear protective gloves.
• Do not operate oven without bulb and cover in
place.
1. Disconnect electrical supply.
2. Remove oven door if desired.
3. Unscrew light bulb cover if so equiped and then light
bulb. Turn counterclockwise.
4. Replace light bulb with 120 volt, 40 watt appliance
bulb.
• Do not overtighten bulb or light bulb cover. They
may be difficult to remove later.
5. Replace light bulb cover and oven door before use.
6. Reconnect power supply.
Replacing Backguard Panel Light
1. Lift up front edge of backguard top trim. Flip top trim
towards rear of backguard.
2. Twist fluorescent bulb to remove it from the sockets.
CAUTION
Wear gloves to protect hands from accidental bulb
breakage.
Removing Storage Drawer
1. Slide drawer out until it stops.
2. Grasp drawer sides near back of drawer.
3. Lift up and out.
• Reverse to reinstall.
Replacing Burner Caps
To replace burner caps after cleaning, make sure cap is
properly aligned and leveled. Verify locating pegs in the
burner body fit into recess in underside of burner cap.
Burner cap must be correctly seated on burner body for
proper operation of burner. Burner will not burn properly if
wrong size burner cap is placed on wrong size burner
body. Check for ignition after placement.
Burner cap
Burner body
Replacing Drip Pans
Drip pans may be removed for cleaning. When replacing
Drip pans after cleaning, holes in drip pan must match
properly with burners. Drip pans will fit properly only one
way.
General Information
