Amana ARGS7650 User Manual

43 RS2310002 Rev. 1
Disassembly Procedures
WARNING
!
To avoid risk of electrical shock, personal injury, or
death: disconnect electrical and gas supply before
servicing.
Gas Valve
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove storage drawer.
4. Disconnect wires and gas lines to gas valve.
5. Remove screws securing gas valve mounting and
remove bracket with valve.
6. Remove screws securing gas valve to bracket.
7. Replace and reassemble in reverse order.
Pressure Regulator
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove storage drawer, for slide-in; or back access
panel, for freestanding.
4. Disconnect gas line from regulator.
5. Disconnect regulator from manifold.
6. Replace and reassemble in reverse order.
Shut-Off Valve
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove storage drawer.
4. Disconnect gas line from shut-off valve.
5. Disconnect shut-off valve from manifold.
6. Replace and reassemble in reverse order.
Power Cord
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power cord from unit.
3. Remove storage drawer.
4. Disconnect power cord plug located behind storage
drawer.
5. Remove screw securing cord to unit.
6. Replace and reassemble in reverse order.
Top Burner Venturi
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove maintop assembly.
4. Slide venturi to the side out of bracket, then slide
back to release venturi from top burner orifice.
Manual/Automatic Oven Door Latch
Assembly
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove maintop assembly.
4. Disconnect and wire terminals.
5. Remove plastic handle from manual latch arm.
6. Remove screws securing latch assembly to chassis.
7. Replace and reassemble in reverse order.
Oven Burner Ignitor
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove storage drawer, oven door, racks, and oven
bottom.
4. Remove Z panel (freestanding only).
5. Disconnect wire terminal plug, located underneath
oven behind storage drawer.
6. Remove screws securing ignitor to oven burner and
oven rear wall.
7. Remove oven ignitor, by sliding ignitor towards front
of the oven, feeding wires through opening.
8. Replace and reassemble in reverse order.
Oven Burner
1. See "Oven Burner Ignitor" procedure (steps 1-3).
2. Remove screws securing oven ignitor and burner.
3. Carefully maneuver burner out of the oven.
4. Replace and reassemble in reverse order.
Broil Burner Ignitor
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove oven door, and racks.
4. Remove screws securing ignitor bracket to oven
tank.
5. Disconnect wire terminals to free ignitor.
6. Replace and reassemble in reverse order.
Broil Burner
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove oven door, and racks.
4. Remove screws securing burner to oven tank.
5. Carefully maneuver burner out of the oven.
6. Replace and reassemble in reverse order.
Lower Burner Box
1. Turn off electrical power and gas to the range.
2. Disconnect gas and power from unit.
3. Remove oven door, and racks.
4. Remove oven ignitor and oven burner.
5. Remove screws securing lower burner box to oven
tank and insulation retainer.
6. Replace and reassemble in reverse order.
